If your Vivo V23 5G (Model: PD2346F) is stuck on the logo, facing bootloop issues, or you simply want to restore it to factory firmware, flashing the stock ROM using SP Flash Tool is the solution.
📥 Firmware Download
🔹 Available Flash File:
- Firmware Name: PD2346F_EX_A_14.0.14.0.W30.V000L1_vivo_mtk_Flash_File
- Chipset Type: MediaTek (MTK)
- Format: Scatter-based firmware package
👉 Download from: androidhub.co.in (or other trusted firmware sites)
⚙️ Flashing Tool & Drivers Needed
- 🔧 SP Flash Tool
Download SP Flash Tool (or from the firmware folder) - 🧩 MTK USB Drivers
Download MTK Drivers
📲 How to Flash Vivo V23 5G (PD2346F) Using SP Flash Tool
📝 Step-by-Step Guide
✅ Step 1: Install MTK USB Drivers
- Install MediaTek USB VCOM Drivers on your PC.
- This ensures your PC detects the phone in preloader mode.
✅ Step 2: Extract Tools & Firmware
- Extract the SP Flash Tool ZIP file to a folder.
- Also extract the Vivo V23 5G firmware package.
- Locate the file named
Android_scatter.txtinside the firmware folder.
✅ Step 3: Launch SP Flash Tool
- Open the SP Flash Tool folder and run
flash_tool.exeas Administrator. - The tool interface will appear.
✅ Step 4: Load Scatter File
- Click the “Scatter-loading” button on the right side.
- Browse to the extracted firmware folder and select the file:
Android_scatter.txt
✅ Step 5: Begin Flashing
- After the firmware loads, click on the Download button at the top.
✅ Step 6: Connect the Device
- Power OFF your Vivo V23 5G.
- Connect it to your PC via USB cable while:
- Holding Volume Down or Volume Up
(If that fails, try connecting without pressing any keys.)
- Holding Volume Down or Volume Up
- SP Flash Tool should automatically detect the phone and start flashing.
✅ Step 7: Wait for Completion
- Wait for the flashing process to complete.
- You will see a green “Download OK” confirmation message once it finishes.
🧩 Post-Flashing Notes
- Disconnect the phone and power it on.
- The first boot may take 5–10 minutes.
- Complete the setup as a new device.
🛠️ Troubleshooting Tips
| Problem | Solution |
|---|---|
| Flashing stuck or fails | Reinstall MTK drivers, use another USB port/cable |
| Phone not detected | Try holding different key combinations (Vol+ or Vol-), or use preloader USB cable |
| Bootloop after flashing | Wipe data/factory reset via recovery mode |
